PortugueseEB-611 J Automatic Edge Bending Machine
Product Details:
- Place of Origin India
- Product Type EB-611 J Automatic Edge Bending Machine
- Usage Industrial
- Automation Semi Automatic
- Supply Ability : 300 Unit Per Day
2150000 INR/Unit
X
Price And Quantity
- 1 Unit
- 2150000 INR/Unit
Product Specifications
- EB-611 J Automatic Edge Bending Machine
- India
- Semi Automatic
- Industrial
Trade Information
- 300 Unit Per Day
- 10 Days
- All India
Product Description
Specification
- Model: EB-611 J
- Name: Edge Band Machine
- Panel Thickness: 10-60 mm
- Tape Thickness: 0.4-3 mm
- Feeding Speed: 14/20/23 m/min.
- Minimum Panel Length: 150 mm
- Minimum Panel Width: 60 mm
- Working Pressure: 6 Bar
- Glue Tank Capacity: 2 kg
- Anti-Adhesive Spray Unit: Standard
- Power of Pre-Milling Unit: 3 kw x 2
- Power of End Trimming Unit: 0.37 kw x 2
- Power of Top & Bottom Trimming Unit: 0.75 kw x 2
- Power of Corner Rounding Unit: 0.75 kw x 2
- Edge Scarping Unit: Numerical analogue Readout
- Spraying Unit: Yes
- Buffing Unit with Cloth Disc: 0.37 kw x 2 & Dia. 155 mm
- Conveyor Motor: 3.7 kw
- Display: Yes
- Total Power: 16.5 Kw
- Overall Dimensions: 6300 x 980 x 1600 mm
- Weight of the machine: 2100 Kg
